DES Labs performs a wide range of mechanical tests on metals, weldments, pipes, and tubes to ensure material integrity
and adherence to global industry standards. Operating from our ISO/IEC 17025:2017 accredited laboratory in Gulbarga,
Karnataka (NABL Certificate Number: TC-9999), we utilize advanced equipment to deliver precise, reliable results. Below
is a detailed overview of our mechanical testing services and state-of-the-art equipment.

Mechanical Testing Services

Tensile Testing

Our tensile testing evaluates material strength, ductility, and other critical properties under tension, ensuring
compliance with standards such as:

• ASTM A370, ASTM E8/E8M, ASTM E21
• IS 1608
• ISO 6892

Capabilities:

• Testing at room temperature and elevated temperatures up to 900°C.
• Determination of Young’s modulus, proof stress (0.01% to 1%), and ultimate tensile strength.
• Suitable for metals, weldments, torsion steel, and other components.

Hardness Testing

We conduct hardness tests to assess material resistance to indentation, adhering to standards including:

• ASTM A370, ASTM E10, ASTM E18, ASTM E92, ASTM E384
• IS 1500, IS 1501, IS 1586
• ISO 6506-1, ISO 6507-1, ISO 6508-1, ASTM A956

Capabilities:

• Brinell hardness (187.5/2.5 to 10/3000 loads).
• Rockwell hardness (A, B, C scales, including superficial N and T scales).
• Vickers hardness (30 kg to microhardness at 10 grams).
• Case depth analysis and portable on-site hardness testing.

Additional Mechanical Tests

• Impact Testing: Charpy and Izod tests to measure toughness, per ASTM E23 and ISO 148.
• Bend and Rebend Testing: Verifies flexibility and weld integrity, compliant with ASTM A370 and
  IS 1599.
• Flattening, Flaring, and Drift Expansion Testing: Ensures formability of pipes and tubes, per
  ASTM A370 and IS 2328.
• Fracture and Fatigue Testing: Assesses material behavior under cyclic loading, per ASTM E647.
• Micro Hardness Testing: Localized hardness analysis for weldments, per ASTM E384.
• Hardenability Testing: Evaluates heat-treated material hardness depth, per ASTM A255.
• Erichsen Cupping Testing: Tests sheet metal formability, per IS 1075.
• Weldment Testing: Includes weld and electrode qualification, minimum leak path, and nodularity
  count, per ASME Section IX and AWS standards.

Advanced Testing Equipment

• Universal Testing Machines (UTM): Capacities of 1 kN, 5 kN, 50 kN, 100 kN, 300 kN, 400 kN, and
  1000 kN, equipped with digital load indicators and extensometers for precise tensile, compression, and bend
  tests.
• Hardness Testers: Automated Rockwell, Vickers, and Brinell testers with calibration for
  accurate measurements across all scales.
• Impact Testing Machines: Automated Charpy and Izod testers with sub-zero electronic bath for
  low-temperature testing.
• Micro Hardness Testers: High-precision systems for micro-scale hardness analysis.
• Fatigue Testing Systems: Servo-hydraulic machines for cyclic loading and fracture toughness
  testing.
• Erichsen Cupping Testers: Specialized equipment for assessing sheet metal formability.
• In-House Specimen Preparation: CNC machining and sample preparation facilities to ensure
  accurate, client-specific test specimens.

Commitment to Excellence

At DES Labs, our mechanical testing services are conducted with precision and efficiency in our NABL-accredited
laboratory. We adhere to international standards (ASTM, ISO, IS, ASME, AWS) to deliver actionable insights with rapid
turnaround times. Our expert team supports industries in ensuring material reliability, safety, and performance.

For more details on our accredited scope, refer to our website or the NABL website.
